A clutch switch is an electrical switch typically installed in the clutch pedal assembly of a vehicle
Short Description: G905-200E01W2 Brand Name:ZINGEAR/Unionwell
Place Of Origin:Guangdong, China (Mainland)
Brand Name:Zingear/Unionwell
P1 Rating:0.1A 125/250VAC 48VDC(Gold plated contact optional)
05 Rating:UL: 5A 125/250VAC
ENEC: 6A 125/250VAC 1E4; 3A 125/250VAC 30VDC 5E4
Initiative Contact Resistance:100mΩMax
Storage Humidity:85%RH Max
Microswitch Details
A clutch switch is an electrical switch typically installed in the clutch pedal assembly of a vehicle. Its main function is to detect the position of the clutch pedal and send that information to the vehicle’s electronic control unit (ECU) or starter circuit. Here’s a breakdown:
Types of Clutch Switches
- Starter Safety Switch (Clutch Interlock Switch)
- Prevents the engine from starting unless the clutch pedal is fully depressed.
- Enhances safety by avoiding unintended movement.
- Cruise Control Clutch Switch
- Disengages the cruise control when the clutch is pressed.
- Ensures the driver maintains control when shifting gears.
- Position or Sensor-type Clutch Switch
- Sends analog or digital signals to the ECU for functions like rev-matching, idle control, or engine braking adjustment.
Working Principle
- Normally open or closed contact: When you press or release the clutch pedal, the switch changes state (open/close), completing or breaking an electrical circuit.
- In modern vehicles, it may be part of a Hall-effect or magnetic sensor system for more precise readings.
Applications
- Manual transmission vehicles
- Motorcycles
- Commercial trucks
- Advanced driver-assistance systems (ADAS)
Common Symptoms of a Faulty Clutch Switch
- Car doesn’t start when pressing the clutch
- Cruise control won’t engage or disengage properly
- Engine stalls when shifting
- Check Engine Light (CEL) may be triggered
If you’re sourcing or specifying a clutch switch, please let me know the use case (e.g., car model, voltage/current specs, type), and I can help with technical specs, product descriptions, or Google keywords.
Related Products
Packing&Shipping
FAQ
Q1: Are you a trading company or manufacturer?
A: yes.we are an original manufacturer specializing in micro switches over 30 years.
Q2: What is your MOQ?
A:Normally,We have only accept the MOQ is 100pcs.
Q3: what is the warranty time?
A: It is about 1-2 years.
Q4: Could you offer us free samples?
A: yes, Afrer the certain design or items is confirmed,free samples could be provided within 2-5 days.
Q5. what is the leading time of mass production? A: About 2-4 weeks.
Q6: what is the capacity per month? A:It is over 8 million pieces per month for micro switch series,and over 20 million pieces per month for keyboard switch series.
