G306 PCB panel mount micro switch is the waterproof type with IP67 protection, so we can use it no matter indoors or outdoors for automotive or home appliances.
MPN: G306-150P41AB-T001
Rating: 0.1A 30VDC, 10mA 14VDC
Contact Arrangement:Â SPDT
Operation Force: 150gf Max.
Operation Position: 7.4±0.8mm(NC), 7.4±0.8mm(NO)
Lever Type:Â Simulated Roller Lever
Protection Level: IP67(IEC)
Sample & Datasheet & Quotation:Â Available
PCB Mount Microswitch Description
The G306-150P41AB-T001 Switch Pictures
Panel Mount Micro Switch Features
G306-150P41AB-T001 is a PCB panel mount micro switch with IP67(IEC) dustproof & waterproof protection level because its outside is sealed. So, we can use it no matter indoors or outdoors for automotive or home appliances. The design of G306 is not only a waterproof function but also a long travel characteristic. Meanwhile, the operating temperature is 40T85 and the rating is 0.1A 30VDC & 10 mA 14VDC with 300000 cycles. Besides, the micro switch also can produce with leading wires, welcome to contact us or visit the G3 series switches page.
G306-150P41AB-T001 Video
Please check the video on youtube to see more about the switch’s appearance.
G306-150P41AB-T001 Micro Switch Datasheet
If need a whole datasheet of the G306-150P41AB-T001, welcome to contact us to get it. OEM or ODM also are welcome!
